Donaldson BOFA · Electronics and soldering fume extractor

V-250

Dual-arm extraction for soldering. Install kit included.

Price $1,155.20

Donaldson list $1,216.00

SKU1U10350595-1209
Airflow
106 cfm
test conditions not stated
Pressure
30 mbar
Inlets
2 × 2.0 in
2 × 50 mm
Power
115 V

Datasheet (PDF)

  • Authorized Donaldson BOFA distributor
  • Ships to the contiguous US · shipping calculated at checkout
  • Business accounts: purchase orders and tax-exempt accepted
  • Current lead time, or shipping to Hawaii, Alaska or outside the US? Send us a message
Request a quote

Need a hose kit or accessories? See hose kits and add-ons or send us a message

Taxes and shipping are calculated at checkout. Buying for a business? Purchase orders and tax-exempt accounts

Hose kits and add-ons

Accessories for the V-250

Listed for the V-250. Open one to check how it connects before you order.

All filters and parts for the V-250
Show all 18 accessoriesShow fewer

Specifications

V-250 specifications

The Donaldson BOFA V-250 is a dual-arm, portable solder fume extraction system for electronics workstations. With 106 cfm airflow, two extraction arms, and installation kit included, the V-250 provides effective fume capture for dual-operator soldering environments. Three-stage filtration delivers 99.995% HEPA efficiency at 0.3 microns with advanced carbon gas filter technology, all in a compact 22 lb unit with less than 61 dB(A) noise level.

V-250 specifications
Application Soldering applications
Controls Not published
Connectivity Not published
Configuration 115 V; install kit
Cabinet Powder-coated
Airflow 106 cfmTest conditions not stated on the datasheet.
Settable airflow range Not published
Pressure 30 mbar
Inlet 2 × 2.0 in · 50 mm
Pre-filter Pad, 96% at 2 µm, pack of 5 · 1UA1030102
Combined filter HEPA 99.995% at 0.3 µm, 3.0 L carbon · 1UA1030099
Other filters Heavy-duty pre-filter, pack of 5 · 1UA1030101
Electrical, as sold 115 V, 60 Hz; 1.1 A full load
Size (H × W × D) 16.5 × 11.4 × 10.6 in
Weight 22 lb
Noise, typical < 61 dB(A)

Documents

V-250 Spec Sheet (PDF)

V-250 / FumeCAB 250 User Manual (PDF)

Included

Install kit

Replacement filters

Filters for the V 250

Order only the ones you’re replacing.

Open in the filter finder

    1. Stage 1 of 2 · Pre-filter pad (pack of 5)

      2 versions · choose one. Match the part number on the label of the pre-filter pad (pack of 5) you’re replacing.

    2. Stage 2 of 2 · Combined HEPA + gas filter

    Not sure which filter you need?

    Send us a message
    Where to find the model and part number

    Model name

    On the rating label on the side or rear of the unit. The label also shows the serial number. Position varies by model.

    Filter part number

    On the label of the filter you’re replacing, for example 1UA1030155. Older labels may show the same number without the 1U.

    Help choosing

    Not sure which setup?

    Tell us about your process and what you need. We’ll help you choose the setup.

    Send us a message

    Buying for a business?

    Purchase orders, tax-exempt accounts and formal quotes.

    Quotes and purchase orders
